P. 33

Yusufeli Bridges,


            Artvin/TURKEY









                Project scope includes

                construction of 3 Balanced
                Cantilever Beam Type and 1

                Incremental Launching
                Method Type viaduct
                structures.

                Construction of Yusufeli
                Dam Viaduct, Şilenkar

                Viaduct and Tekkale Viaduct
                have been completed as of                                                                                        Yusufeli Dam Viaduct Şilenkar Viaduct
                2022. Works are still ongoing                                                                                    Length: 340m                    Length: 530 m

                for Yusufeli Viaduct.                                                                                            Width: 14,5 m,                  Width: 16,5 m
                                                                                                                                 Max Pier Height: 83 m           Max Pier Height: 152 m

                                                                                                                                 Tekkale Viaduct                 Yusufeli Viaduct

                                                                                                                                 Length: 644m                    Length: 695m
                                                                                                                                 Width: 15 m                     Width: 16,5 m,
                                                                                                                                 Max Pier Height: 137 m          Max Pier Height: 152 m
