Ataköy Multi-purpose Sports

Hall, Structural Steel Works,

İstanbul/TURKEY

Total dead weight of the roof
structure was 2.100 tons and

the main trusses of a single

arch resting on columns were

spanning 114.540 mm.
Average dead weight of a

main truss was 230 tons;

these trusses were fabricated
and erected in three pieces.

The roofing structure of the closed sports hall accommodating 22.000
spectators was constructed.

Within the system there existed 3 units of transverse bent main roof

trusses and 17 units of vertically spanning purlin pipes.

2 units of longitudinal skylight trusses connecting the main trusses and

purlins and a skylight system framing the side elevation were erected.
